CityWall, Modular Security Walling System

CityWall, Modular Security Walling System

Be the first to review this product

A security walling system developed to offer a deterrent and protection against manual and burglar break-in.

Used for security applications in:

  • Pharmacy

  • Embassies

  • Cash Handling / Storage Facilities

  • Banking Halls

  • Security Containment

  • Local Authorities

  • Security Printers

  • Military

  • Utilities Facilities

  • Panic Rooms & Safe Rooms

  • Railway Control / Switch Gear Rooms

  • Police stations


The modular approach of the CityWall system makes it extremely versatile in application, panels can be used to create security lining material to existing rooms, or they can be used to construct a secure barrier; or to construct a complete enclosure with walls and ceilings. The panel finish can be left electrogalvanized steel or  covered in various cladding finishes such as drywall or otherwise.

Get special prices on security wall panels today!

Availability: In stock

  • Specifications
  • Details
  • Product Description
  • Additional Information
  • Reviews
  • Product Tags


CityWall 80 (80mm thick) certified to:
- EN1627-30, Level RC4
- EN1522, Level FB4 and FSG

• Alternative material finishes : painted
steel, range of cladding materials
• Integration of Gunnebo doors
• Lighting and alarms systems
• Security ceilings


Panel Weight
CityWall 80 55Kg/m2

Securtiy Rated Resistance
CityWall has been tested to physical attack resistant standards EN1627-30 level RC4, which covers attack by powered and mechanical tools.

The CityWall partitions have also been tested to apply ballistic resistance according to EN1522 European Standards.

Thermal Insulation
The inner core mineral wool insulation offers a thermal conductivity value of 0.037 W/mK and a thermal resistance is 2m² K/W.

The CityWall is made from electrogalvanized steel plates with insulation and additional materials to meet the above standards.
The modular panels are available in standard height 2300 mm and 1200, 900,600, 300 mm width.

Other sizes can be supplied to suit site requirements. Cutouts can be made during manufacture to accommodate ATM facias and other
equipment protruding though the enclosure wall.

CityWall can be fi tted with other security doors and vault doors as well as custom built doors. When fitted with a door set the door must carry the corresponding accreditation in order to maintain the security level.


CityWall’s core attributes are the

  • Speed of installation
  • Versatility
  • Lightweight construction.

This results in costs savings over more traditional methods, and total flexibility with the installation over heavier panels, especially when on upper floors of building etc.
